Reasons and Solutions for poor cleaning effect of conveyor belt cleaner

The belt cleaner is a device used to remove the adhesion on the surface of the belt during the transportation of materials. If the belt cleaner cannot even guarantee the cleaning effect, it will lose its value.

The incomplete cleaning of the belt cleaner will cause the material adhered to the belt to directly enter between the drum and the belt, causing friction between material particles, the belt, and the drum, and finally leading to the wear of the drum and the belt. transport efficiency.

There are primary and secondary belt cleaners. The primary cleaner is installed on the driving drum of the belt conveyor and is used to remove the sticky material on the working surface of the belt. The secondary cleaner is installed in front of the drum at the end of the belt conveyor or on the lower branch belt where the vertical weight device is redirected to the drum and is used to remove the sticky material on the non-working surface of the belt.

Reasons and Solutions for the poor cleaning effect of conveyor belt cleaner

1. Incorrect selection of cleaner

The selection of the cleaner should be based on the on-site working conditions, and the selection should be carried out in a targeted manner. It is not possible to blindly install a cleaner that does not match the working conditions.

2. Incorrect position for installation

Different types of cleaners have different installation positions. For specific installation details, please consult Bai-Ott.

After the cleaner is installed and used for some time, it is prone to cause different degrees of wear to the scraper due to the frequent friction between the scraper and the belt surface. There will be a certain gap between the scraper and the belt after abrasion, which may cause a poor cleaning effect  when the fit between the two is not enough.

3. It is necessary to check the cleaner frequently, adjusting and replacing the scraper in time once it is found to be seriously worn, to ensure its cleaning effect and prevent the return of the belt material.

4. The blockage at the cleaner will cause the deformation of the cleaner, and it will also cause the installation angle between the cleaner and the belt to change, resulting in a poor cleaning effect.

The installation angle between the cleaner and the belt should be measured frequently. If the angle changes, it should be adjusted in time.

If you have any questions during use or installation, please contact our professional technicians.
